4
1 Untie the wire on the AC ADAPTER (16).
2 Plug the AC ADAPTER into appropriate wall
outlet.
3 Plug the small end of the adapter into the
ADAPTER JACK (12) on the back of the unit.
Getting Started
Unpacking
1 Remove packing materials from unit.
Note: Save all packing materials.
2 Remove plastic bag covering radio.
3 Remove AC ADAPTER from packing.
4 Remove tie from A/C ADAPTER.
5 Open lid and remove styrofoam shipping
material from turntable.
6 Remove black tie-wrap from under the tone
arm.
7 Remove white protective needle cover by gently
pulling towards the front of the unit.
8 Turn the TURNTABLE SUSPENSION SCREW
(31) clockwise until it is all the way down.Do
not force or over tighten it. This allows the
turntable to float on its shock absorbers.
9 Release tone arm hold down clip by gently
pushing to the right. This will unlock tone arm
from its arm rest. Re-lock the hold down clip
when moving the unit to another location.
Power Source
