6

1. Install Trim Brackets 3. Install Grease Tray

2. Install Regualtor with hose 4. Install the Grill Head

Model: TCS4FL (built-in Model)

Phillips Head Screw

M6X15

Qty.4

Part # S112M06151

Pre-assembled

Screws

ENGLISH
