PARTS LIST
KEY DESCRIPTION PART# QTY
21B Side Shelf Cap, Right P01122002E 1
22A Universal Hose Barb P03905002A 1
20B Regulator with Hose (50mbar) P03640016A 1
23 Trolley Panel, Top P01004099D 1
24 Trolley Panel, Left P07605049B 1
25 Trolley Panel, Right P07606053B 1
26 Trolley Panel, Rear P07624010B 1
27 Trolley Panel, Bottom P01004096J 1
28 Trolley Frame, Front P07201009B 1
29 Trolley Frame, Rear P07201010B 1
30 Tank Fastening Strap (LPG) P05314016V 1
31 Trolley Door, Left Y0410031 1
32 Trolley Door, Right Y0410032 1
33 Handle Spacer P00303222A 1
34 Door Handle P002051242 1
35 Caster Seat P05327075W 1
36 3" Caster with Brake, Front P05112038A 1
3" Caster with Brake, Rear P05112039A 1
37 3" Caster without Brake, Front P05112040A 1
3" Caster without Brake, Rear P05112041A 1
38 Trolley Trim Panel P07501022R 1
39 LED Light Wire P05373012B 1
40 Battery Pack for LED P05301013B 1
41 Name Plate P00403009D 1
Cover(Optional) P07007073B 1
Plancha(Optional) P05701058B 1
Hareware Pack P06033004A 1
Operator's Manual P80196010A 1
KEY DESCRIPTION PART# QTY
1 Hood Assembly P0014761KA 1
2 Temperature Gauge P00601601C 1
3 Temperature Gauge Seat P00614047E 1
4 Warming Rack W295 P01507035H 1
5 Warming Rack D100 P01507036H 1
6A Cooking Grid W295 P01615068H 2
6B Cooking Grid W281 P01615067H 1
7 Grill Bowl Assembly P00736027E 1
8 Burner/Main P020050364 4
9A Burner Bracket, Lower P02213467A 1
9B Burner Bracket, Upper P02213477A 1
9C Gas collector box (cross lighter) P02212425A 1
10 Gas Valve/Manifold Assembly - 30mbar Y0060866 1
- 50mbar Y0060867 1
11 Electric Wires Set/Electrode P02614017A 1
12A Protective Pad P05518112K 2
12B Protective Pad P05518113K 2
13 Electric Ignitor,4 ports P02502484F 1
14 Control Panel P02914471S 1
15 Control Knob Seat P03447014A 4
16 Control Knob P03444022V 4
17A Grease Tray Heat Shield P06904072C 1
17B Grease Tray P0270643RG 1
17C Grease Receptacle P02701387G 1
17D Grease Receptacle Front Panel, Right P07508018W 1
18 Side Shelf Connecting Bracket, Left P01202009B 1
19 Side Shelf Connecting Bracket, Right P01203009B 1
20 Side Shelf P01106055B 2
21A Side Shelf Cap, Left P01123002E 1
Model: TCS4PL
