INPUT MODE AMP MODE CHANNEL ASSIGNMENTS USE THIS PRESET WHEN YOU ARE USING:
NAME STEREO/INPUT Y DUAL/BRDGE CHANNEL 1 CHANNEL 2
JBL 3631 INPUT Y DUAL Low Frequencies Mid-High Frequencies the JBL 3631 in bi-amp mode
3631T-LF STEREO BRIDGE Low Frequencies Low Frequencies the JBL 3631 in tri-amp mode
3631T-MH INPUT Y DUAL Mid Frequencies High Frequencies the JBL 3631 in tri-amp mode
JBL 3632 INPUT Y DUAL Low Frequencies Mid-High Frequencies the JBL 3632 in bi-amp mode
3632T-LF STEREO BRIDGE Low Frequencies Low Frequencies the JBL 3632 in tri-amp mode
3632T-MH INPUT Y DUAL Mid Frequencies High Frequencies the JBL 3632 in tri-amp mode
JBL 4622 INPUT Y DUAL Low Frequencies Mid-High Frequencies the JBL 4622 in bi-amp mode
JBL 4632 INPUT Y DUAL Low Frequencies Mid-High Frequencies the JBL 4632 in bi-amp mode
4632T-LF STEREO BRIDGE Low Frequencies Low Frequencies the JBL 4632T in tri-amp mode
4632T-MH INPUT Y DUAL Mid Frequencies High Frequencies the JBL 4632T in tri-amp mode
4675C4LF INPUT Y DUAL Low Frequencies Mid-High Frequencies the JBL 4675C4 in bi-amp mode
5674-LF STEREO BRIDGE Low Frequencies Low Frequencies the JBL 5674 in tri-amp mode
5674-MH INPUT Y DUAL Mid Frequencies High Frequencies the JBL 5674 in tri-amp mode
JBL 4641 STEREO BRIDGE Subwoofer Subwoofer the JBL 4641 in subwoofer mode
JBL4642A STEREO BRIDGE Subwoofer Subwoofer the JBL 4642A in subwoofer mode
JBL8330A STEREO DUAL
Full Range with 40 Hz
highpass fi lter
Full Range with 40 Hz
highpass fi lter
the JBL 8330A in passive crossover applications
Table 1: DSP Preset Information
