Amplificadores de potencia
page 24
Leistungsendstufen
Amplificateurs de puissance
DSi Series Power Amplifiers
Operation Manual Mode d'emploi Bedienungsanleitung Manual de Operación
INPUT MODE AMP MODE CHANNEL ASSIGNMENTS USE THIS PRESET WHEN YOU ARE USING:
NAME STEREO/INPUT Y DUAL/BRDGE CHANNEL 1 CHANNEL 2
JBL4622N STEREO DUAL Full Range Full Range the JBL 4622N in passive crossover applications.
JBL4622 INPUT Y DUAL Low Frequencies High Frequencies the JBL 4622 in bi-amp mode.
JBL3632 INPUT Y DUAL Low Frequencies High Frequencies the JBL 3632 in bi-amp mode.
3632T-MH INPUT Y DUAL Mid Frequencies High Frequencies the JBL 3632 in tri-amp mode and are powering MF and HF.
JBL4639 INPUT Y BRIDGE Low Frequencies Low Frequencies the JBL 3632 or 4632 in tri-amp mode and are powering LF.
JBL4632 INPUT Y DUAL Low Frequencies High Frequencies the JBL 4632 in bi-amp mode.
4632T-MH INPUT Y DUAL Mid Frequencies High Frequencies the JBL 4632 in tri-amp mode and are powering MF and HF.
JBL4675C INPUT Y DUAL Low Frequencies High Frequencies the JBL 4675C in bi-amp mode
5674-MH INPUT Y DUAL Mid Frequencies High Frequencies the JBL 5674 in tri-amp mode and are powering MF and HF.
JBL5644 INPUT Y DUAL Low Frequencies Low Frequencies the JBL 5674 in tri-amp mode and are powering LF.
JBL4641 INPUT Y DUAL Sub Frequencies Sub Frequencies the JBL 4641 subwoofer.
JBL4642A INPUT Y DUAL Sub Frequencies Sub Frequencies the JBL 4642A subwoofer.
JBL8340A STEREO DUAL Full Range Full Range the JBL 8340A subwoofer.
JBL8330A STEREO DUAL Full Range Full Range the JBL 8330A surround.
Table 1: DSP Preset Information
