INSTALLATION & OPERATION MANUAL 10093 REV 0 (04/21)
PAGE
4
OF 12
G T S
SERVICE CONNECTIONS
SERVICE CONNECTIONS
GAS CHARACTERISTICS
DIMENSIONS
* For use on non-combustible floors only.
BTU/HR kW/HR Supply Pipe Pressure (W.C)
GTS-30
684 lbs.
[310 kg]
80,000 23.4
Natural
7” - 14”
(178 mm - 356 mm)
Propane
11” - 14”
(279 mm - 356 mm)
Sides 0
GTS-40
725 lbs.
[328 kg]
100,000 29.3 Back
6”
(152 mm)
SERVICE CONNECTIONS
- COLD WATER: 3/8” O.D. tubing to faucet (OPTIONAL)
– HOT WATER: 3/8” O.D. tubing to optional faucet (OPTIONAL)
–
Less than 2 amperes.
A B C D E F G H
J
Ø2 Ø3
GTS-30
30 Gallons
(114 liters)
49.63”
(1257 mm)
40.75”
(1035 mm)
33.5”
(851 mm)
23.5”
(597 mm)
43.13”
(1095 mm)
37.5”
(953 mm)
43”
(1092 mm)
71.88”
(1826 mm)
42”
(1067)
46.5
(1181)
GTS-40
40 Gallons
(152 liters)
58.63”
(1489 mm)
40.25”
(1022 mm)
43.5”
(1105 mm)
23”
(584 mm)
52.13”
(1324 mm)
37.5”
(953 mm)
42.13”
(1070 mm)
71.88”
(1826 mm)
