INSTALLATION & OPERATION MANUAL 10093 REV 0 (04/21)
PAGE
6
OF 12
G T SINSTALLATION
G C
WARNING
Do not connect the appliance to the electrical supply until after the gas connection has been made.
All gas supply connections and any pipe joint compound used must be resistant to the action of propane gases.
The gas inlet is located under the control panel on the left-hand side.
Connect gas supply to the tilting braising pan. The gas supply line must be at least the equivalent of 3/4” iron pipe with an
incoming pressure of approximately 7” W.C. (Water Column) for natural gas or 11” W.C. (Water Column) for propane gas.
Make sure the pipes are clean and free of obstructions, dirt and piping compound.
manifold is set at 3.5” W.C. (Water Column) for natural gas, and 10” W.C. (Water Column) for propane gas.
WARNING
CAUTION
petroleum or propane gases.
After piping has been checked for leaks, all piping receiving gas should be fully purged to remove air.
E C
WARNING
ELECTRICAL GROUNDING INSTRUCTIONS
This appliance is equipped with a three-prong (grounding) plug for your protection against shock hazard
and should be plugged directly into a properly grounded three-prong receptacle. Do not cut or remove the
grounding prong from this plug. (120V units only).
The electrical wiring diagram is located inside the left-hand skillet console.
The wiring compartment is located in the left hand control console. For units operated on electrical supply other than 120
volts, remove the left hand console cover and make electrical connections per the wiring diagram located inside. The
skillet must be grounded in accordance with requirements of the National Electrical Code or applicable local code.
Replace console cover.
WARNING
For an appliance equipped with casters, the installation shall be made with a connector that complies with the Standard
for Connectors for Moveable Gas Appliances, ANSI Z21.69-CSA 6.16 and a quick-disconnect device that complies with
the Standard for Quick-Disconnect Devices for Use with Gas Fuel, ANSI Z21.41-CSA 6.9; adequate means must be
provided to limit the movement of the appliance without depending on the connector and the quickdisconnect device
or its associated piping to limit the appliance movement; the location where the restraining means may be attached to
the appliance is the bottom rear of the left hand controlconsole.
quick disconnect and strain relief.
