SECTION 3 - INSTALLATION
WHEN USING EXISTING HOLES
1. Remove the old wall
bracket, taking care not to
damage existing fittings.
(See Fig. 1)
fig. 1
SECTION 4 - INSTALLATION
WHEN DRILLING NEW HOLES
fig. 2
fig. 3
2. Screw the new Flexi-Fix
bracket into the existing holes.
(See Fig. 2)
3. Install the Flexi-Fix Wall
Mounted Accessory and
tighten the grub screw to
secure in place. DO NOT
overtighten the grub screw.
(See Fig. 3)
1. Place the Flexi-Fix bracket
onto the wall and mark hole
centers for drilling.
DO NOT attempt to install
with screws going into
grouting.
(See Fig. 4)
fig. 4
fig. 5
fig. 6
2. Drill holes and insert wall
plugs. Ensuring the wall plugs
sit flush with the wall.
(See Fig. 5)
3. Install the Flexi-Fix Wall
Mounted Accessory and
tighten the grub screw to
secure in place. DO NOT
overtighten the grub screw.
(See Fig. 6)
