2. Product data
Independently developed by Meishan, The hydraulic tool MS-BT20 with nose
assembly MS-7880L equipped, installs 1/2” Mono-tail. The tool is characterized by
long service life, light weight, easy operation and low noise.
2.1 Specification
P.N. of Tool
MS-BT20
P.N. of Nose
MS-7880L
Operating temp. range
°C
0-60
Noise
dBA
45±3
Max. Vibration
m/s²
2
Weight of Tool
kg
3
Effective Displacement
mm
51.5
PULL Pressure(installation)
MPa
28-30
PUSH Pressure(installation)
MPa
15-20
PULL Pressure(cutting)
MPa
35-40
PUSH Pressure(cutting)
MPa
15-20
Standards
EN 2006/42/EG
