Parts Listing
DESCRIPTION Part Number
1 Side Panel, Left SMT-C400002
2 Side Panel, Right SMT-C400003
3 Top Cover SUB-C400007
4 Lamp, Logo ELE-C100419
5 Cover, Back SMT-C400005
6 Solenoid, Low Pressure 24V DC (3 in unit) POU-C400001
7 Support Bracket, Rear Upper (2 in unit) SMT-C400008
8 Support Bracket, Front (2 in unit) SMT-C400007
9 Water Outlet PLC-C400015
10 Bulkhead Ftg, JG 1/4 x 1/4 POU-C000003
11 Bulkhead Ftg, JG 1/4 x 1/4 POU-C400012
12 Solenoid, High Pressure POU-C400002
13 Leak Detector Assy SUB-C400014
14 Panel, Lower Front SUB-C400035
A Refrigeration System N/A
A1 Cold Control REF-C400004
A2 Overload REF-C100300
A3 Relay REF-C100229
A4 Cover, Compressor PW2.5DV REF-C100301
B Upper Front Panel Assy SUB-C400033
B1 Upper Front Panel, Black N/A
B2 Grill, Drip Tray PLC-C400011
B3 Drip Tray Base PLC-C400009
B4 Cover, UV N/A
B5 PCB, UV Display N/A
B6 PCB, Push Button Module N/A
B7 Bracket, Push Button, Black N/A
C Middle Front Panel Assy, Black SUB-C400034
C1 Middle Front Panel, Black N/A
C2 Bracket, Cup PLC-C400007
C3 Door Lock PLC-C400008
C4 Cup Dispenser, Outer PLC-C400023
C5 Cup Dispenser, Inner PLC-C400024
C6 Spring, Cup Dispenser FAS-C400011
C7 Cup Dispenser Bottom PLC-C400022
D Top Shelf & Reservoir N/A
D1 Top Shelf SMT-C400013
D2 Transformer (120V/18V/1A) ELE-C400033
D3 Reservoir, Ambient PLC-C400001
D4 Lid, Reservoir PLC-C400002
D5 Float, Electronic ELE-C400026
D6 Float Valve, Mechanical POU-C400005
D7 UVC LED Module, 0.8W, 12-24 VDC ELE-C100401
D8 Water Outlet, SS, UV SMT-C100235
E Hot Tank Assy SUB-C400001
E1 Hot Tank, SS N/A
E2 Heater Band ELE-C100298
E3 Heat Limiter ELE-C100170
E4 Thermostat ELE-C100109
F PCB, Box & Cover Assy SUB-C400037
F1 PCB Box PLC-C400017
F2 Cover, PCB PLC-C400018
F3 Main PCB, UVC ELE-C100416
F4 Power Switch, Green ELE-C400007
F5 Power Switch, Red ELE-C400006
F6 Fuse, 10Amp ELE-C400032
F7 Power Cord ELE-C400029
G 3/8” Pusht Connector Assembly N/A
G1 DM Elbow, 1/4 x 3/8(AEU0604), Gray POU-C100071
G2 In-Line, Screen Filter, 3/8 (70 Mesh) POU-C100063
G3 “C” Clip, 8mm, Plastic MIS-C100222
G4 Union, JG 3/8 x 1/4 POU-C100026
G5 Tube, SS, 9.5mm OD x 95mm SMT-C100220
Parts Not Shown
Adjustable Foot MIS-C400006
Filter Bracket SMT-C400006
