Locate water dispenser
5. Un-package and assemble the bottle adaptor assembly (located in the bottle storage area).
3. Clean the outside of new bottle with a clean cloth (Figure 5).
6. Place the bottle adaptor probe into the bottle (Figure 7).
2. Place fresh bottle outside of the cabinet.
1. Place the water cooler on a flat level surface in a cool shaded location near a grounded wall outlet.
2. Position water dispenser so that the back of the unit is a minimum of 4 inches / 10 cm away from the wall
to ensure proper ventilation (Figure 3).
Install water bottle
1. Slide the door upward to access bottle area (Figure 4).
4. Remove bottle cap completely from the top of the bottle (Figure 6).
7. Slide the bottle adaptor over the neck of the bottle and push down to secure (Figure 8).
8. Push probe down until the tube hits the bottom of bottle (Figure 9).
9. Remove the red plug from the SmartFlo™ water line and install onto the bottle adaptor assembly (Figure
10). Save the red plug for future use.
10. Slide bottle into cabinet and close the door by sliding downward (Figure 11).
THANK YOU FOR BUYING A CRYSTAL MOUNTAIN WATER COOLER!
GETTING STARTED
Figure 3
Figure 4 Figure 5 Figure 6 Figure 7
Figure 8 Figure 9 Figure 10 Figure 11
Page 08
