11 V4-02-2011
ORDERING DATA
Order no. Description
0699.0401 FA 400 dew point sensor for refrigeration driers, -20...50 °Ctd
0699.0402 FA 400 dew point sensor for adsorption driers, -80...20 °Ctd
0699.0403 FA 400 dew point sensor, -60...30 °Ctd
0533 0112 Cable FA 200 to FA 400
0553.0104 Connection cable, length 5 m
0553.0105 Connection cable, length 10 m
0553.0106 Alarm cable, length 5 m
0553.0107 Alarm cable, length 10 m
0699.3390 Standard measuring chamber for compressed air up to 16 bar
0699.3590 High pressure measuring chamber up to 350 bar *
0699.3690 Measuring chamber for atmospheric dew point
0699.3790 Measuring chamber for respiratory air bottles up to 350 bar
0699.4004 Special scaling, output in ppm, V/V, % RH, mg/m³
0699.3495 Mains unit in wall housing 230 VAC/24 VDC with alarm processing
0554.0002 Control and calibration set 11.3 % RH
0554.0004 Control and calibration set 33 % RH
0554.0005 Control and calibration set 75.3 % RH
0554.2005 CS Service Software for VA/FA 400 sensors incl. PC connection set, USB
connection and interface adapter to the sensor as well as
CS Soft Professional incl. USB-cable A-A
3200.0003 Precision calibration at 0 °Ctd and 10 °Ctd incl. ISO certificate
0699.3396 Precision calibration at -40 °Ctd incl. ISO certificate
0699.4003 * Special version FA 400 for 350 bar
