CSI CSI-DSP85-P - Operating Power Parameters; Environmental Requirements

-17 -
OIP3 Measured with 2 CW tones at 14
dBm/tone
Linear Output Power +27 dBm max Uplink and Downlink
CELL +26 dBm **
PCS +25 dBm** ** AGC Set Point
Noise Figure (Avg) 5.0 dB At Maximum Gain
Operating Power Parameters
Parameter Specification Notes
Maximum RF input Power +10 dBm
without damage
Linear Gain 85 dB Factory Calibrated Gain
Pass Band Ripple +/-1.5 dB
Automatic Gain Control (AGC) 30 dB max In 0.5 dB steps
range
Manual Gain Control 53.5-85 dB max In 0.5 dB steps
RMS Vector Error (EVM) 3% max TDMA, EDGE, W-CDMA, CDMA2000
CDMA RHO 0.98 min CDMA2000, 1x-EVD0
Spurious Emissions &
Applicable Documents
FCC -13 dBm max Per FCC part 2, 22 and/or 24
Industry Canada -13 dBm max
Propagation Delay <2.5 usec
Input VSWR (Typ) <1.5:1
+ 43 dBm
Environmental Requirements
Parameter Specification Notes
Relative Humidity 5% to 95% Non-condensing
Industrial Dust <15mg/m3 Telcordia GR-63-CORE
Temperature Range -30 to +48 C
(-22 to +118 F)
0
0
00
1dB Compression Uplink and Downlink
+ 33 dBm
Connectors N-Female (2)
