GH DRIVER
◆
Wiring
◆
Trial run
04
●
For risk of injury and fire, please ensure that the voltage of the main circuit AC input
power and the rated voltage of the driver are consistent.
●
Please do not conduct withstand voltage and insulation test to the controller arbitrarily.
Otherwise, the semiconductor and other components in the controller may be damaged.
●
For risk of fire, please connect braking resistor and braking unit according to the wiring
diagram.
●
Please do not connect the AC input power cord to the output U, V, W terminals.
Otherwise, damage to inside of the controller may be caused.
●
For risk of fire and malfunction of the controller, please tighten the terminals of main
loop and control circuit with appropriate torque.
●
Please do not connect the phase shifting electrolytic capacitor and LC / RC noise filter
to the output circuit. Otherwise, damage to inside of the controller may be caused.
●
Please do not connect the electromagnetic switch and electromagnetic contactor to
the output circuit to connect or disconnect the load. During loaded operation of the
controller, the surge current will cause protection circuit action of the controller.
●
For risk of electric shock and short circuit, please do not touch the terminals of the main
circuit directly after power-on.
●
Please confirm the input and output signals to guarantee safe operation. Malfunction of
the system will cause casualties and damage to the work piece and nearby equipment.
●
For risk of injury, alarm reset only can be done after ensuring that the operating signal
is cut off. Alarm reset with operating signal will lead to suddenly re-start.
●
For risk of driver burning, the inside of long term stored driver shall be checked for
water and condensation.
●
For risk of electric shock and burning the equipment, it’s prohibited to touch the
terminals of the driver with hand during operating.
●
For risk of scalding, the running servo driver and motor may have a high temperature
rise, please do not touch.
●
For risk of scalding and electric shock as the braking resistor has a high temperature
rise for discharging, please do not touch.
●
For risk of damage to the equipment and accident, please do not change the settings
of the drive arbitrarily.
Caution
Caution
Danger
To Next Page
