US • 11
Chosen mode: ”RECOND”
MULTI US 7002 has a Recond mode which is used to recondition a battery that has been
severely discharged. The battery is first charged using the mode ”NORMAL”. When the
analysis phase is complete, the charger begins reconditioning the battery by providing a
constant current of 1.5A and a maximum voltage of 15.7V. After 0.5–4 hours, the battery
is completely reconditioned and the charger goes into pulse maintenance. The battery is
ready to be used, or store it with pulse maintenance active until you are ready to use the
battery. Recond is indicated by lamp E and lamp 6. Note that the recond phase begins
with normal charging and that the charger therefore will indicate the charging phases ac
-
cording to the descriptions above first. Lamp 6 is first lit when the reconditioning begins
INDICATORS
SUPPLY
NORMAL
SUPPLY
RECOND
RECOND
MODE
1
0
A
B
C
D
E
2
3
4
5
6
Indication Description
0 Error mode, the charger suspends the charging / voltage maintenance.
See further description below.
1 Start mode.
2 Bulk charging, maximum voltage.
3 Absorption charging, voltage limited to chosen voltage.
4 Pulse maintenance charging
5 Supply mode, fixed output voltage, no counter voltage requirement.
6 Recond charging
A STANDBY
B Mode ”NORMAL” (14.4V)
C Mode ”SNOWFLAKE” (14.7V)
D Mode ”SUPPLY” (13.6V)
E Mode ”RECOND” (15.7V, 1.5A 0.5–4h)
