CTEK Z4200 - Administrative Access

10 October 2016
2
Setting or Parameter
Factory Default
Firewall Status
Enabled – See security section below
WAN Ping Response
Disabled – See security section below
NAT Traffic to WAN
Enabled – See security section below
XML Interface
Disabled – See security section below
IP White List
Disabled – See security section below
SMS Management
Disabled – See security section below
SMS White List
Disabled – See security section below
SSH (Secure Shell) Access
Disabled – See security section below
SSH User ID
root – See security section below
SSH Password
pass – See security section below
Enable HTTPS
Disabled – See security section below
Connection State (WAN)
Enabled
Relay Input (Trigger Input)
Disabled
Relay Output (Managed by Automation Control)
No
Time Source
Cellular Network
Location Source
GPS (Internal)
DNS Address Source
Acquire from Wireless Network
Auto Configure (radio firmware)
Disabled
Radio module firmware
Sprint - SWI9X15C_05.05.63.01 or newer
Figure 1
2.2 Administrative Access
All administration and configuration of the Z4550 is accomplished using the web UI, which can be accessed locally
throughout the Ethernet connection or over the air through the WAN connection after the unit is connected to a cellular
network.
To use the local interface connect a computer to the Z4550’s Ethernet port using a standard Ethernet cable. Using a web
browser connect to the login page using the administrative IP address and the default login and password. Once you are
successfully logged in the Quick Panel display shown in Figure 2 will be presented.
