12
More Generate Timecode Set Starts the timecode at a
pre-defined time. Select ‘Set’ then the
cursor will move to tens of hours. Press the up or down key to adjust tens of hours.
Then press the right arrow to move to hour units and adjust using up/down. The
cursor may be moved between columns as required with the left and right keys.
When adjusted as required press ‘select’ to return to the menu functions.
More Generate Timecode FPS Set to generate at 24/25/29.97 or 30
frames per second.
Note: The timecode generator is not crystal locked and may lose or gain a few
seconds per hour, it is intended as a test not a reference generator, it may be
however also be useful for jam syncing several devices.
More/Tone Loop
Tone loop enables output tone output and audio input at the same time. Input and
output signals may be selected to analogue or AES formats with adjustable input and
output gain and adjustable frequency. This is useful for testing operation of external
equipment, checking frequency response etc. Analogue signals are output on the left
channel output XLR and input on the left channel input XLR. AES signals are output
on both AES channels and input may be selected to monitor/meter left or right
channels.
More ToneLoop Input Available inputs Analogue, AES BNC L, AES
BNC R, AES XLR L, AES XLR R, SPDIF BNC L,
SPDIF BNC R.
More ToneLoop Output Available Outputs Analogue, AES BNC, AES XLR,
SPDIF BNC.
More ToneLoop IPgain Input gain adjustable -10dBm to +70dBm on
analogue input or -10dBm to +12dBm on AES
inputs.
More ToneLoop Freq Frequency adjustable in third octave steps 50Hz
to 20kHz.
More ToneLoop OPgain Output level adjustable from -60dBm to
+12dBm.
