CTP Systems dBbox3 - Cable Test and Delay Features; 2 W Listen Channel Selection; 2 W Listen Gain; Cable Test

13
More/ 2W Listen
This will listen to and meter unbalanced audio inputs on pins 2 and 3 of the left XLR
input with pin 1 as common earth. It is not suitable for use with Clearcom beltpacks
due to their call signaling system.
More 2W listen Listen Select to listen to channel 1 (XLR pin 2),
Channel 2 (XLR pin 3) or both.
More 2W listen Gain Adjust input level gain from -10dB to +12dB
More/ Cable Test
Test XLR, BNC and MIDI DIN cables. XLR will indicate open circuit, phase reversed
and in phase connections on XLR pins 1, 2 and 3. BNC will test the centre (live)
conductor only. MIDI DIN will check MIDI connections (DIN pins 4 and 5). The clicking
noise heard when using this function is a relay disconnecting the XLR earth in order
to test it.
More/More (select even more)
More/More/Delay
This provides a delay of up to 80mS in mono or 40mS in stereo.
If AES is used please note this feature will only function correctly at 48kHz.
More More Delay Input> Select analogue, AES BNC, AES XLR or SPDIF
BNC input(s).
More More Delay Output> Select analogue, AES BNC, AES XLR or SPDIF
BNC output(s)
More More Delay Delay> Select up to 80mS delay in mono or 40mS in
stereo. If set above 40mS and mode is then set
to stereo this will default to (and display) 40mS.
More More Delay Mode> Set to mono or stereo delay
More More Delay OP Mon> Switch on to monitor the delayed signal. Use
the volume controls to adjust level.
