Cub Cadet 1027 User Manual

24
Model 1027
Ref.
No.
Part No. Description
1.
17962 Switch Plate
2.
650-0007 Steering Tube Assembly
3.
683-0033A Steering Support Bracket
4.
683-0178A Front Axle Assembly: RH
5.
683-0179A Front Axle Assembly: LH
6.
710-0224 Hex Screw AB
7.
710-0459A Hex Screw 3/8-24 x 1.5” Gr.5 Sp.
8.
710-0643 Lock Screw 5/16-18 x 1.0” Gr.5
9.
710-0689 Hex Screw 1/2-13 x 0.75”
10.
710-0837 Oval C-Sunk Screw #10-16 x 0.625”
11.
710-0958 Hex Screw 1/4-20 x 1.25 Gr.5 Sp.
12.
710-1017 AB Screw 1/4-14 x 0.625”
13.
710-1611 Self-Tapping Screw 5/16-18 x 0.75”
14.
710-3008 Hex Screw 5/16-18 x 0.75”
15.
712-0116 Lock Nut 3/8-24
16.
712-0206 Hex Nut 1/2-13
17.
712-0241 Hex Nut
18.
712-0267 Hex Nut
19.
712-0324 Lock Nut 1/4-20
20.
712-0411 Lock Nut
21.
712-0711 Jam Nut
22.
714-0470 Cotter Pin
23.
723-0156 Ball Joint
24.
726-3046 Ratchet Clip
25.
731-0511 Trim Strip
26.
735-0265A Floor Pad: LH
27.
735-0266A Floor Pad: RH
28.
736-0105 Bell Washer
29.
736-0119 Lock Washer
30.
736-0160 Flat Washer
31.
736-0169 Lock Washer
32.
736-0187 Flat Washer
33.
736-0196 Flat Washer
34.
736-0242 Belleville Washer
35.
736-0272 Flat Washer
36.
736-0320 Flat Washer
37.
736-3078 Flat Washer
38.
737-3007 Grease
39.
738-0541 Spacer
40.
738-3089A Steering Adapter
41.
741-0225 Hex Flange Bearing
42.
741-0356 Bearing: Steering Column
43.
747-0955 Tie Rod
44.
748-0290 Pinion Gear
45.
750-0532 Spacer
46.
783-0411 Gear: Steering Segment
47.
783-0565B Upper Frame Cover
48.
783-0566A Lift Plate
Ref.
No.
Part No. Description
