22
SECTION 11: PARTS LIST FOR MODEL 1027
Ref.
No.
Part No. Description
1 731-2295 Steering Wheel
2 731-2296 Steering Wheel Insert
Ref.
No.
Part No. Description
1.
731-1919 Steering Column: Black
2.
731-1857 Control Knob
3.
712-0142 Hex Nut 8-32
4.
710-3217 Pan Head Machine Screw #8-32
5.
710-0599 Hex Screw TT 1/4-20 x .50
6.
710-0514 Hex Screw 3/8-16 x 1.0
7.
712-0431 Lock Nut
8.
749-1099-
0716
Bumper Tube: Front, Yellow
2
4
3
1
5
6
5
8
7
7
2
1
