15
Illustrated
Parts List
To order replacement
parts, contact your
local Cub Cadet dealer;
or call our dealer
locator number at
1 (877) 282-8684;
or log onto
www.cubcadet.com
8
Ref. Part No. Description
1 747-1161A Control Handle
2 736-0451 Saddle Washer
3 736-0524B Blade Bell Support
4 710-1044 Hex Bolt
5 747-0710 Hinge Pin
6 749-1092A Upper Handle
7 710-1205 Rope Guide
8 710-1174 Carriage Bolt
9 749-0928A Lower Handle
10 720-0279 Wing Nut
11 720-04072 Star Knob
12 714-0104 Hairpin Clip
13 746-0957 Control Cable 37.25”
14 726-0240 Cable Tie
15 17098 Hinge Clip
16 731-04019 Trail Shield
17 682-0139 20” Cutting Deck Assembly
18 742-0740 20” Mulching Blade
19 720-0426 Height Adjustment Knob
20 732-0404 Spring Lever
21 734-04226 Wheel Assembly 8 x 2.125
22 736-0504 Wave Washer
23 731-2626 Deluxe Bail Cover
Ref. Part No. Description
24 731-0982A Hubcap: Radial Spoke Gray
25 738-0507B Shoulder Bolt
26 687-02077A Pivot Arm Assembly - RH Front
Pivot Arm Assembly - LH Rear
687-02076A Pivot Arm Assembly - LH Front
Pivot Arm Assembly - RH Rear
27 687-02106 Handle Bracket Assembly RH
687-02107 Handle Bracket Assembly LH
28 748-04096 Blade Adapter
753-0588 Blade Adapter Kit (for service)
29 732-0731 Torsion Spring
30 687-02075A Height Adjust. Assembly LH
687-02074A Height Adjust. Assembly RH
31 782-7006 Mounting Bracket
32 736-0270 Bell Washer
33 710-0599 Hex Washer Hd. TT Screw
34 710-0654A TT Sems Screw
35 731-1409B Chute Deflector
36 682-7002 Mulching Plug Assembly
37 712-04065 Hex Lock Nut
38 787-01290 Height Adjustment Plate
39 782-5012 Rear Baffle 10.62 X 2.66
40 17033A Front Baffle 10.62 RAD X 3.03
NOTE: For painted parts, please refer to the list of
color codes below. Please add the applicable color
code, wherever needed, to the part number to order
a replacement part. For instance, if a part numbered
700-XXXX is painted Cub Yellow, the part number to
order would be 700-XXXX-0716.
Cub Yellow: 0716
Powder Black: 0637
