The interlock safety switches, activated by the brake
pedal, PTO switch and seat switch serve to prevent
starting the engine accidentally. The engine will not
start unless: 1. the brake pedal is depressed, 2. the
PTO is in the "OFF" position, 3. the operator is
seated.
H. LIFT HANDLE (1204 and 1210 Tractors Only)
The lift handle is used to lift or lower equipment used
with the tractor. The equipment can be set in multiple
positions by depressing the button on the handle and
releasing it when the desired position is reached.
An additional feature has been provided to give
increased float capability to the deck by depressing
the button and rotating the pin into the slot as shown
in Figure 8.
3
Figure 9. (1211 Tractor Only)
1. Hydraulic Lift Control Lever
J. LIFT HEIGHT INDICATOR
The lift height indicator will Indicate the height of deck
attachment when installed. (See Figures 10 and 11.)
Figure 8. (1204 and 1210 Tractors Only)
1. Lift Handle
2. Slot
3. Button
4. Pin
I. HYDRAULIC LIFT CONTROL LEVER (1211
Tractor Only)
■ i^NOTE
The engine must be running in order to op*
erate the hydraulic lift.
The hydraulic lift control lever (see Figure 9 ) controls
the raising and lowering of a mowing deck, if installed.
The control lever is spring-loaded. To raise the equip¬
ment, move the lever back toward the tractor seat. To
lower the equipment, move the lever forward.
LIFT
O HEIGHT
INDICATOR
Figure 10. (1204 and 1210 Tractors Only)
