8
SPECIFICATIONS
Engine: 15HP Kawasaki or 18HP Briggs & Stratton
Type: Vertical air cooled V-Twin
Air Cleaner: Paper element
Lube System: Pressurized with oil filter, drain valve with hose
Starter: 12-volt electric
Traction Drive: Engine to two variable-speed integrated hydraulic pump and
wheel motors on each drive wheel
Cutter Deck;Drive: 44" belt driven
Clutch: Electric
Deck Lift: Hand lever w/ lock for height adjustment
Cutting Height: 1-1/2" to 4"
No. of Blades 3, belt-driven, power take-off from engine
Controls: Engine ignition and start switch; throttle & choke; left and right
steering levers; electric blade clutch switch; parking brake; mower
deck lift
Parking Brake: Mechanical linkage attached to the brake handle
Front Caster Wheels: 11 x 5.00 - 5
Tire Pressure: 8-10 psi rear, 20-25 psi front caster
Drive Wheels: 18 x 8.50 - 8
Frame: Structural steel, all welded construction
Seat: Adjustable seat. 4" Adjustment, optional arm rests
Fuel Tank: One 5 gallon with shut off valve
Ground Speed: 0-7 MPH forward. 0-3 MPH reverse
Instrumentation:
(Optional)
Hour meter, Tachometer, Maintenance-minder,
Net Weight: 598 lbs w/44" deck
