SPECIFICATIONS
GENERAL INFO.
Controls: Engine ignition and start switch; throttle & choke; left and right
steering levers; electric blade clutch switch; parking brake;
mower deck lift
Parking Brake: Mechanical linkage attached to the brake handle
Seat: Weight adjustable suspension seat with adjustable seat back
and armrest. 4" Adjustment front-to-rear
Frame: Structural steel, all welded construction
Instrumentation: Hour meter
Front Caster Wheels: 11 x 6.00 - 5
Drive Wheels: 20 x 8.00-10 for 44” & 48”; 20 x 10.00-10 for 54”
Tire Pressure: 8-10 psi rear, 20-25 psi front caster
Fuel Tank: Two 5 gallons with individual shut off valves
Ground Speed: 0-8 MPH forward. 0-4 MPH reverse
Net Weight: 655 lbs 44”; 670 lbs 48”; 685 lbs 54”
ENGINE INFO.
Engine: 19HP Kawasaki 44”; 21HP Kawasaki 48”; 23HP Kawasaki 54”
Type: Vertical air cooled V-Twin
Air Cleaner: Paper element and foam precleaner
Lube System: Pressurized with oil filter, drain valve with hose
Starter: 12-volt electric
Clutch: Electric blade brake clutch
TRACTION DRIVE INFO.
Traction Drive: Variable-speed integrated hydraulic charged ZT-2800 pumps
and wheel motors on each drive wheel
CUTTER DECK INFO.
Cutter Deck;Drive: 44", 48”, 54” belt driven fabricated deck
Deck Lift: Foot lever w/ lock for height adjustment
Cutting Height: 1-1/2" to 4" in 1/4” increments
No. of Blades: 3, belt-driven, power take-off from engine
