Page #70 background image
70
Briggs & Stratton Engine Model 12T102
Ref. Part No. Description
356 BS-695814 Wire-Stop
358 BS-791797 Gasket Set-Engine
365 BS-699484 Screw (Carburetor)
415 BS-693463 Plug (Crankcase Cover)
445 BS-491588s Filter-Air Cleaner Cartridge
455 BS-692591 Cup-Flywheel
456 BS-692299 Plate-Pawl Friction
459 BS-281505s Pawl-Ratchet
504 BS-695383 Washer Set-Friction (Control Bracket)
505 BS-691251 Nut (Governor Control Lever)
522 BS-798503 Plug-Dipstick/Fill
535 BS-493537s Filter-Air Cleaner Foam
552 BS-692346 Bushing-Governor Crank
562 BS - 691119 Bolt (Governor Control Lever)
597 BS-691696 Screw (Pawl Friction Plate)
601 BS-791850 Clamp-Hose (Green)
608 BS-795930 Starter-Rewind
613 BS-699209 Screw (Muer)
615 BS-692576 Retainer-Governor Shaft
616 BS-692547 Crank-Governor
619 BS-699230 Screw (Cylinder Head Plate)
621 BS-692310 Switch-Stop (Brake)
632 BS-693408 Spring/Link-Mechanical Governor
633 BS-693867 Seal-Choke/Throttle Shaft (Choke Shaft)
635 BS-692076 Boot-Spark Plug
663 BS-699206 Screw (Control Panel)
741 BS-695087 Gear-Timing
668 BS-694257 Spacer (Control Bracket)
689 BS-691855 Spring-Friction
692 BS-797624 Spring-Detent
718 BS-690959 Pin-Locating
742 BS-692564 Retainer-E Ring
746 BS-790278 Gear-Idler
819 BS-699233 Screw (Muer Bracket)
830 BS-797441 Stud-Rocker Arm
832 BS-693583 Guard-Muer
836 BS-699632 Screw (Muer Guard)
851 BS-493880s Terminal-Spark Plug
868 BS-795440 Seal-Valve
883 BS-691893 Gasket-Exhaust
914 BS-699480 Screw (Rocker Cover) (M6x15.8mm)
BS-797444 Screw (Rocker Cover) (M6x9.5mm)
Ref. Part No. Description
951 BS-790630 Lever-Choke
957 BS-799719 Cap-Fuel Tank
968 BS-791082 Cover-Air Cleaner
971 BS-798649 Screw (Air Cleaner Base to Carburetor)
972 BS-799863 Tank-Fuel
975 BS-797631 Bowl-Fuel
987 BS-797629 Seal-Throttle Shaft
993 BS-694088 Gasket-Cylinder Head Plate
1005 BS-692592 Fan-Flywheel
1022 BS-691890 Gasket-Rocker Cover
1023 BS-499924 Cover-Rocker
1026 BS-790287 Rod-Push
1029 BS-797443 Arm-Rocker
1034 BS-691343 Guide-Push Rod
1036
Label-Emissions (Available from a Briggs
& Stratton Authorized Dealer)
1070 BS-699201 Screw (Flywheel Fan)
1095 BS-791798 Gasket Set-Valve
1137 BS-694258
Screw (Control Bracket) (High Speed
Control)
1147 BS-798458 Nut (Control Bracket) (Friction)
1210 BS-791849 Pulley/Spring Assembly (Pulley)
1211 BS-791849 Pulley/Spring Assembly (Spring)
1329 N/A Replacement Engine
1395 BS-690370 Screw (Air Cleaner Base)
