9
SPECIFICATIONS
GENERAL INFO.
Controls: Engine ignition and start switch; throttle; choke; left and right
steering levers; electric blade clutch switch; parking brake;
mower deck lift
Parking Brake: Internal, mechanical linkage attached to the brake handle
Seat: Adjustable seat with armrests. 5" Adjustment (fore-aft)
Frame: 2” Steel square tube and plate, all welded construction
Instrumentation: Hour meter, Tachometer, Maintenance-minder
Front Caster Wheels: 11 x 4 - 5.00
Drive Wheels: 23 x 9.5 - 12 Turf Pro
Tire Pressure: 8-10 psi Rear, 20-25 psi front caster
Fuel Tank: Two 5 gallon w/individual shutoff valves
Ground Speed: 0-8.0 + MPH forward. 0-4.3 MPH reverse
Net Weight: 863 lbs. w/60" deck
ENGINE INFO.
Engine: 23 HP Kohler, 23 HP Kawasaki
Type: Vertical crankshaft, air cooled V-Twin
Air Cleaner: Paper Element
Lube System: Pressurized with oil filter
Hydraulic System: 2 quarts and 1 pint filter per transaxle
Starter: 12-volt electric
Blade Brake Clutch: Electric
TRACTION DRIVE INFO.
Traction Drive: Engine to two variable-speed hydraulic pump/motor, Hydro-Gear
ZT-2800 transaxles
CUTTER DECK INFO.
Cutter Deck;Drive: 60", Belt Driven
Deck Lift: Hand lever w/pin lock for height adjustment
Cutting Height: 1-1/2" to 4"
No. of Blades 3, belt-driven, power take-off from engine
