Cub Cadet 31AE9P3W710

25
9
Parts List
REF
NO.
PART
NUMBER
DESCRIPTION
1 05244B Housing, Bearing
2 784-0315A Housing, Double D Bearing
3 618-0436 Gear Box Assembly, Auger
4 618-0281A Bracket Ass’y, Auger Brake
5 684-0090B Impellar , 16”
6 684-04234 Housing, Auger - 45”
7 684-04151 Spiral Ass’y, LH
8 684-04152 Spiral Ass’y, RH
9 710-0371 Screw, Hex Cap Lock
10 710-04527 Screw, Carr, Stnls Stl
11 710-0451 Screw, Carr, 5/16-18 x .75
12 710-0459A Scr, Hex Cap, 3/8-24 x 1.5
13 710-0528 Scr,Hex Cap, 5/16-18 x 1.25
14 710-04484 Screw, 5/16-18 x .750
15 726-04012 Nut, Push
16 710-3008 Screw, 5/16-18 x .75 GR5
17 710-04526 Screw, Carr,3/8-16 x 1.0
18 710-04606 Scr., 5/16-18 x .4300
19 711-0677 Ferrule
20 712-0116 Nut, Hex Lock, 3/8-24
21 712-04063 Nut, Flnge Lk, 5/16-18
22 712-04065 Nut, Flg Lk, 3/8-16
23 712-04102 Nut, Hex, Stnls Stl, 3/8-16
24 714-0104 Pin, Internal Cotter
25 714-0126 Key, Hi Pro, 3/16 x 3/4
26 714-0135 Key, Woodruff, 1/4 x 3/4
27 714-04040 Pin, Bowtie Cotter
28 715-0118 Pin, Spirol, 5/16 x 1.75
29 725-0157† Tie, Cable
30 731-1696A Adapter, Chute, 6”
31 736-04216 Washer, Bell, .34x.87x.06
32 731-05163 Spacer, 1.0 x 1.5 x 1.0Lg
33 731-2635 Clip, Mounting
34 731-2643 Tool, Cleanout
35 732-0858 Spring, Extension
36 736-0159 Wash, Fl, .349 x .879 x .063
37 736-0174 Wash,, .625 x .885 x .015
38 736-0242 Washer, .34 x .872 x .06
39 750-04020 Spacer, 1.004 x 1.375 x .25
40 629-0071 Extension Cord, 110V
41 736-3008 Washer, .344 x .75 x .12
REF
NO.
PART
NUMBER
DESCRIPTION
42 736-3046A Washer, 1.01 x 1.86 x .06
43 738-0281 Screw, Shoulder, .625 x .17
44 738-04155 Pin, Shear, .25 x 1.75
45 738-04159 Shaft, Spiral, — 45”
46 741-0192 Bearing, Flange w/Flats
47 741-04024 Bearing, Self Aligning
48 741-0475 Bushing, Nylon
49 741-0494 Bushing, Flange,
50 747-0980A Rod, Auger Idler
51 749-1117 Tube, Support
52 754-0222A Belt, V, 1/2 x 44
53 756-0178 Pulley, Flat Idler, 2.75 OD
54 756-0243 Pulley, Auger Drive, 10.0
55 784-0385B Bracket, Auger Idler
56 790-00264 Bracket, Gear Box Support
57 784-5123 Bracket, Chute Crank
58 710-0276 Scr., Carr., 5/16-18 x 1.00
59 737-3000 Ftg., 3/16
60 790-00195A Plate, Shave, — 45”
61 736-04215 Washer, Bell, .37x.87x.06
62 790-00199 Shoe, Skid, Stnls Stl
63 710-04525 Screw, Carr., 5/16-18 x .75
64 712-04103 Nut, Hex, Stnls Stl,
65 721-0146 Oil Seal
66 618-0246 Hsg, Ass’y, Auger, RH (Incl.
Ref. # 65 & 70)
67 618-0435 Hsg, Ass’y, Auger, LH (Incl.
Ref. # 65 & 70)
68 710-1260A Scr, LD, 5/16-18 x .750
69 711-1133 Shf, Drive, Auger
70 741-0670 Flange Bearing
71 716-0111 Ext, Ret, Ring
72 717-1425 Gear, Worm, LH
73 721-0145 Seal, Oil
74 736-0266 Wash, Flat, 1.52ID x 2.0 OD
75 736-0291 Wash, Flat, .88 ID x .38 OD
76 737-3000 3/16 Drive Lube Fitting
77 738-0275 Shf, Gear, Worm
78 741-0184 Brg, Thrust
79 741-0217 Sleeve
80 721-0325 Plug
† Not Shown
To order replacement
parts, call the Customer
Dealer Referral Line at
1-877-282-8684,
or visit
www.cubcadet.com to
find the nearest Cub
Cadet service dealer in
your area.
