Cub Cadet 31AE9P3W710

27
9
Parts List
REF
NO.
PART
NUMBER
DESCRIPTION
1 625-0007A Assembly, Light
2 646-0012 Cable Ass’y, Auger/Drive
3 684-0053B Crank, Chute, 26.0
4 705-5218 Handle, Engage, RH
5 705-5219 Handle, Engage, LH
6 705-5266 Bracket, Chute Crank
7 710-0458 Screw, Carr., 5/16-18 x 1.75
8 710-0572 Screw, Carr., 5/16-18 x 2.5
9 710-1003 Screw, #10-16 x .625
10 710-1625 Screw, #10-24 x 1.75
11 710-1878 Screw, Hex, 3/8-16 x 1,75
12 710-1879 Screw, Hex, 3/8-16 x .88
13 710-3015 Screw, Hex, 1/4-20 x .75
14 711-0677 Ferrule, 5/16-18 x .312 Dia
15 784-5679 Brkt., Handle Support - LH
16 712-04064 Nut, Hex Flange, 1/4-20
17 712-3010 Nut, Hex, 5/16-18 GR5
18 714-0101 Pin, Internal Cotter
19 714-0104 Pin, Internal Cotter
20 720-0201A Knob, Crank
21 720-04039 Knob, Shift
22 720-04072 Knob, Star, 5/16-18
23 725-0157 Tie, Cable
24 784-5682 Brkt., Handle Support - RH
25 784-5681 Brkt., Handle Support - LH
26 726-0100 Cap, Push, 3/8
27 731-0061 Panel, Handle
777I22545 Graphic, Auger/ Chute Tilt
777D10457 Graphic, 945 SWE
28 736-0105 Wash, Bell, .375 x .87 x .063
29 736-0185 Wash,Fl., .375 x .738 x .063
30 736-0242 Wash, Bell, .34 x .872 x .06
31 736-0275 Wash, Fl, .344 x .688 x .065
32 741-0475 Bushing, Plastic, .38 ID
33 746-0950A Cable Assembly, Trigger
34 747-0624 Rod, Chute Crank
35 747-0983A Rod, Lower Shift
36 747-0997 Rod, Upper Shift
REF
NO.
PART
NUMBER
DESCRIPTION
37 784-5680 Brkt., Handle Support - RH
38 749-0989A Handle, Upper LH
39 749-0990A Handle, Upper RH
40 749-0991 Handle, Lower
41 750-0963 Connector, Shift Rod
42 684-0102A Panel, Handle
43 710-0276 Screw, Carr, 5/16-18 x 1.0
44 710-0458 Screw, Carr., 5/16-18 x 1.75
45 710-0459A Screw, Hex, 3/8-24 x 1.5
46 710-0597 Screw, Hex, 1/4-20 x 1.0
47 710-0599 Screw, Hx, 1/4-20 x .5
48 710-0805 Screw, Hex, 5/16-18 x 1.5
49 710-0895 Screw, Hx,1/4-15 x .75
50 711-0653 Pin, Clevis, .312 x 1.0
51 712-0116 Nut, Insert, 3/8-24
52 712-04063 Nut, Flnge Lk, 5/16-18
53 714-0507 Pin, Cotter, 3/32 x .75
54 731-0846C Chute, Upper, 6.0
777S32280 Graphic, Danger
55 731-0851A Flange Keeper, Chute
56 731-0903D Chute, Lower
57 731-1313C Cbl. Guide, Chute Tilt
58 732-0145 Spring, Compression
59 732-0193 Spring, Compression
60 732-0746 Spring, Torsion
61 735-0199A Bumper, Rubber
62 784-5619B Handle, Shift
63 736-0231 Wash, Fl, .344 x 1.125 x .12
64 736-0119 Washer, Lock, 5/16
65 736-0509 Wash, Fl, .35 Sq x .72 x .134
66 746-0902 Cable, Chute Control, 66”
67 746-0903 Cable, Chute Control w/Clip,
68 747-0877 Rod, Cam
69 748-0362 Cam, Handle Lock
70 748-0363 Pawl, Handle Lock
71 784-5594 Bracket, Cable
72 784-5604A Handle, Chute Tilt
To order replacement
parts, call the Customer
Dealer Referral Line at
1-877-282-8684,
or visit
www.cubcadet.com to
find the nearest Cub
Cadet service dealer in
your area.
