Installing / Removing Mulch Baffle
Before installing or removing the
mulch plug, disengage blades, stop the engine and
remove key if so equipped to prevent unintended
starting.
Stop the engine and wait for all parts to stop moving.
Installing the Mulch Baffle
Insert the right-side tab (A) of the baffle into the bracket on 

Insert the mulch baffle into the discharge opening (B), See 2.


towards the rear of the mower (C) to secure it in place.

Removing the Mulch Baffle
Slide the baffle to the right (toward the front of the mower) to
disengage the slot from the mower deck and then pry the left-
side of the baffle outward.
B
C
A

se c t i O n 5 — Op e r a t i O n

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Cub Cadet CC 760ES and is the answer not in the manual?

Cub Cadet CC 760ES Specifications

General IconGeneral
Drive SystemSelf-Propelled
Deck MaterialSteel
Number of Blades1
Drive TypeRear-wheel drive
Mulch CapableYes
Side DischargeYes
Rear BagYes
Wheel Size (Front)8 inches
Engine Type4-Cycle
Cutting Height Positions6
Speed SettingsVariable
EngineOHV
Start TypeRecoil
Fuel Capacity1.3 quart
Engine Displacement190cc
Wheel Size (Rear)8 inches
Fuel Tank Capacity0.5 gallons
