Cub Cadet CC3224 User Manual

10 Section 3 — ASSembly & Set-Up
Wand to Gun
2. Connectwandtogun.Tightensecurely.
Figure 3-3
Hose to Gun
1. Attachhighpressurehosetogun.Tightensecurely.
Figure 3-4
Set-Up
Gas and Oil Fill-Up
Refertotheseparateengineowner’smanualforadditional
engineinformation.
1. Addoilprovidedbeforestartingunitforthefirsttimeout
ofthebox.
2. Servicetheenginewithgasolineasinstructedinthe
separateengineowner’smanual.
WARNING: Useextremecarewhenhandling
gasoline.Gasolineisextremelyflammableandthe
vaporsareexplosive.Neverfuelthemachine
indoorsorwhiletheengineishotorrunning.
Extinguishcigarettes,cigars,pipesandother
sourcesofignition.

Cub Cadet CC3224 Specifications

General

Engine Displacement	208cc
Pressure	3200 PSI
Flow Rate	2.4 GPM
Engine	Cub Cadet OHV
Hose Length	25 ft
Pump	Axial cam
Wheels	10 in
