Assembly & Set-Up
3
9
Contents of Carton
• OnePressureWasher • OneHandle • OneSprayGun
• OnePressureWasherOperator’sManual • OneHighPressureHose • FiveQuick-ConnectNozzles
• OneEngineOperator’sManual • OneQuick-ConnectSprayWand • OneBottleofOil
Nozzles
1. Removethecoloredquick-connectnozzlesfromtheplastic
bagandinsertthemintocorrectgrommetonthenozzle
holder.Nozzlesarecolorcodedtomatchcolorednozzles
onlabel.
Figure 3-2
Assembly
NOTICE: Thisunitisshippedwithoutgasolineoroilin
theengine.Fillupwithgasolineandoilasinstructedinthe
accompanyingenginemanualBEFOREoperatingyourmower.
NOTICE: Thehigh-pressurepumpwasfilledwithoilatthe
factory.Alwayscheckoillevelbeforeusing(refertoMaintenance
&Adjustmentsformoreinformation).
Handle
1. Slidethehandleassemblyontotheframeandsecurewith
saddleboltsandknobs.
NOTICE: Riskofpersonalinjury.Avoidplacinghandsbetween
handleandframewhenassemblingtopreventpinching.
Figure 3-1
