10 Section 3 — ASSembly & Set-Up
Wand to Gun
1. Connect wand to gun. Tighten securely. See Figure 3-3.
Figure 3-3
Hose to Gun
1. Attach high pressure hose to gun. Tighten se cure ly. See
Figure 3-4.
Figure 3-4
Set-Up
Gas and Oil Fill-Up
Refer to the separate engine owner’s manual for additional
engine information.
1. Add oil provided before starting unit for the first time out
of the box.
2. Service the engine with gasoline as instructed in the
separate engine owner’s manual.
WARNING: Use extreme care when handling
gasoline. Gasoline is extremely flammable and the
vapors are explosive. Never fuel the machine
indoors or while the engine is hot or running.
Extinguish cigarettes, cigars, pipes and other
sources of ignition.
