Cub Cadet Challenger 700

Chassis
5‐12
Inspect the Front Brake Discs
 Inspect for galling or damage.
 Measure brake disc deflection in 4
spots approximately 90 degrees
from each other.
Brake disc maximum
deflection
0.10 mm (0.004 in)
 Brake disc thickness (1)
 Wheel hub (2)
 Rim (3)
Brake disc minimum thickness
3.0 mm (0.12 in)
