Cub Cadet Challenger 700

Electrical
6‐13
Checktheignitioncoilresistance.
Connectmultimeterasshown.
Positiveleadtoorangeleadterminal.
Negativeleadtoignitioncoilbase.
Primarycoilresistance
0.18–0.28Ohms
Testsecondarycoilresistance.
Connectmultimeterasshown.
Positiveleadtotheorangelead
terminal.NegativeleadtoSparkPlug
Lead.Secondarycoilresistance
6.32–9.48KOhms
Replacethesparkplugwire
Replacetheignitioncoil
Replacethemainswitch
Testthemainswitchforcontinuity.
Out o
f
Speci
f
ication
Both Tests meet specification
cor
r
ect Incor
r
ect
TesttheA.Cmagnetocouplingresistance.
Connectmultimeterasshown.
Positiveleadtowhite/redterminal(1)
Negativeleadtowhite/greenterminal(2)
Pickupcoilresistance
459–561Ohms
TesttheA.Cmagnetocouplingresistance.
Connectmultimeterasshown.
Positiveleadtoredterminal(3)Negative
leadtowhite/blueterminal(4)Pickup
coilresistancesecondary
0.063–0.077Ohms
inco
r
r
ect
Replacethepickup
coil/statorassembly
Meets s
p
eci
f
ication
Checkthesparkplugwireresistance.
10Kohms
