Periodic Maintenance and Adjustment 8-16
1. Oil filler cartridge 2. Torque wrench
7. Install the engine oil drain bolt, and then
tighten it to the specified torque.
Tightening torque:
Engine oil drain bolt:
30Nm (3.0m·kgf, 22 ft·lbf)
8. Add the specified amount of recomm-
ended engine oil, and then install the
engine oil filler cap and tighten it.
Recommended engine oil:
See page 10-2.
Oil quantity:
Without oil filter cartridge replacement:
1.9 L (1.67 lmp qt, 2.01 US qt)
With oil filter cartridge replacement:
2.1 L (1.85 lmp qt, 2.22 US qt)
CAUTION:
In order to prevent clutch slippage (since
the engine oil also lubricates the clutch),
do not mix any chemical additives. Do
Tightening torque:
Oil filter cartridge:
17Nm (1.7m·kgf, 12 ft·lbf)
To Next Page
