Control Functions 4-7
kilometers per hour press the right side
button on the display. This will also change
the displayed mileage from miles to
kilometers.
Clock time adjustment
Press the left button and hold for three
seconds and the clock goes into the hour
‘set’ mode.
1. Press the right button to set the hour.
2. Press the left button again and the clock
goes into the minute ‘set’ mode.
3. Press the right button to set the minutes.
4. Press the left button again and the clock
will exit the ‘set’ mode.
Four-wheel drive indicator “
”
There are two 4WD indicators on the display
panel. The left 4WD indicator has a blinking
circle on the front axle when the grey and
yellow 4WD selector buttons are pressed to
indicate the “4WD” function has been
activated. This position also indicates that
the Front differential is NOT locked. This
allows the wheels on the left and right sides
to rotate at different speeds to accommodate
turning.
Differential gear lock indicator
The right 4WD symbol will show an ‘X’ over
the center of the front axle when the lever is
moved to the right and the yellow differential
gear lock button is set to out position, which
means the differential is not operational and
is locked. When riding an UTV on muddy and
slippery roads or when climbing a steep hill,
