Cub Cadet CLT 160

11
SECTION 8: CONTROLS
Figure 1
A PTO (Power Take-Off) Knob*
PTO (Power Take-Off) Lever*
G
H
Parking Brake Button
Cruise Control Button
B Indicator Monitor/Hour Meter I Ignition Switch
C Choke Control (if so equipped) J Brake Pedal
D Shift Lever K AutoDrive
™
Pedal
E Cup Holder L Lift Lever
F Throttle Control Lever M Seat Adjustment Lever
N Cargo Net (Not Shown)
I
F
B
C
H
G
E
L
K
J
M
P
1
/
1
0
P
+
A*
D
NOTE: Steering Wheel not shown for clarity.
NOTE: Style varies by model.
A*
NOTE: Any reference in this manual to the RIGHT or LEFT side of the tractor is observed from operator’s position.
*Tractors vary by model and are equipped with either a PTO lever or a PTO knob, NEVER both.
