Section 2— ASSembly & Set-Up10
3. Move blade to down position.
4. Remove cotter pins from tie rods (1). See
Figure 2-24.
5. Remove tie rod by pushing end of
rod through the bracket (2), and then
rotating rod to align rod tabs to slot in
bracket. Slide rod out of bracket (3). See
Figure 2-24.
1
2
3
Figure 2-24
6. Slide plow assembly out of mounting
brackets. See Figure 2-25.
Figure 2-25
Note: Pulling up slightly on the plow
assembly may make sliding the plow out
of the brackets easier.
Note: The FastAttach™ brackets
(689-00685/689-00686) may be left
in place for use with the 19A30038100
FastAttach™ Brush Guard and other
front FastAttach™ Attachments.
FastAttach™ Front Attachments
Description Part Number
All-Season Plow 19A30037100
Brush Guard 19A30038100
More coming soon. Visit your local Cub Cadet Dealer or CubCadet.com for more information.
FastAttach™ Rear Attachments
Spreader (100 lb capacity) 19A30028100
Cargo Carrier (80 lb capacity) 19A30029100
Bagger (42" and 46" Decks) 19A30030100
Sprayer / Cargo Carrier Combo 19A30035100
More coming soon. Visit your local Cub Cadet Dealer or CubCadet.com for more information.
To optimize your experience in the snow, consider these convenient attachments:
Tire Chains (for 20" rear tires) 490-241-0023
Tire Chains (for 22" rear tires) 490-241-0025
Rear Weight Kit 490-900-M060
Snow Cab 19A40022100
