Section 2 — ASSembly & Set-Up
5
Part Number Description Qty.
- 689-00677 Hardware Pack 1 1
1 712-04065 Nut 4
2 710-3001 Screw 3/8-16 X .880 GR5 4
30 710-06012A Fixing Bolt 3/8-16 X .125 GR5 4
- 689-00678 Hardware Pack 2 1
1 712-04065 Nut 4
3 714-3020 Internal Cotter Pin 2
4 736-04183 Washer .395 X 1.0 X .62 4
5 710-0514 Screw 3/8-16 X 1 GR5 4
- 689-00679 Hardware Pack 3 1
1 712-04065 Nut 1
6 603-0297 Eye-Bolt 1
7 710-1625 Oval Head Screw #10-24 X 1.75 2
8 710-3180 Hex Head Bolt 5/16-18 X 1.75 2
11 710-3008 Screw 5/16-18 X .75 GR5 3
12 712-04063 Flange Lock Nut 5/16-18 5
13 712-3004A Hex Flange Nut 1
14 936-0414 Teon Washer .570X1.120x.062 1
15 738-0143 Shoulder Screw .498 Dia X .340 1
29 736-0451 Curved Washer 4
- 689-00680 Hardware Pack 4 1
16 703-0650 Blade Skid Shoe 2
17 912-3048 Hex Nut 2
18 712-04150 Nut 2
- 689-00688 Hardware Pack 5 1
1 712-04065 Nut 4
5 710-0514 Screw 3/8-16 X 1 GR5 2
12 712-04063 Flange Lock Nut 5/16-18 2
19 710-04683C Self-tapping Screw 3/8-16 X 1 1
20 710-3008 Screw 5/16-18 X .75 GR5 2
21 710-3181 Screw 1/2-13X1.50 GR5 1
22 710-3261 Screw 3/8-16 X 7.00 GR5 1
23 712-3022 Hex Nut Ctr Lk 1/2-13 2
24 732-04345 Extension Spring 1
25 936-0208 Washer .51 X 1.5 X .07 1
26 736-0234 Flat Washer .390 Id X 1.50 Od X .075 1
27 938-0507B Shoulder Screw 1
- 689-00666 Hardware Pack 6 1
9 710-0451 Carriage Bolt 5/16 - 18 .750 6
10 712-0429 Hex Nut 5/16 - 18 .750 6
28 714-0209 Cotter Pin 2
To Next Page
