Forward Drive Belt
Remove the reverse drive belt as instructed in the previous
section.
2.
Remove the idler pulley bolt and move the belt from under
The forward idler belt will not clear the belt keepers near 4.
the engine pulley. You must remove the reverse idler
bracket to allow the belt to move off of the engine pulley.
Remove the two securing screws and move the bracket
toward the transmission pulley. Retain the screws for
Remove the belt from the reverse idler pulley and then 5.
To reassemble the new belt, follow the instructions in 6.
reverse order. Be sure to place the wider side of the belt
away from the engine and transmission pulleys.
NOTE: Upon reassembly, make certain that the idler pulley
on the bottom of the keeper and the alignment when
reassembling with the replacement belt.
18 se c t i O n 7— se r v i c e
