10
GENERAL INFO.
Controls: Engine ignition; throttle; choke; left and right operator presence
levers; left and right steering/brakes; blade clutch; transmission
shift
Parking: Transmission in 1st, neutral latches released, rear wheels
chocked in front
Frame: 7 gauge steel
Front Caster Wheels: 9 x 4.0-5 semi-pneumatic
Drive Wheels: 13 x 6.50-6 pneumatic, 10-12 psi
Fuel Tank: 5 gallons, regular unleaded
Ground Speed:
(approximate)
1st=2.0mph, 2nd=2.6mph, 3rd=3.1mph, 4th=4.0mph,
5th=6.0mph, Reverse=2.2mph
Net Weight: 460 lbs
ENGINE INFO.
Engine: 12.5 Briggs I/C, recoil start, dual element air cleaner
Oil Type: SAE 15W40, 1.2 quart
Spark plug: 759-3336, 0.030” gap
TRACTION DRIVE INFO.
Traction Drive: 5 speed forward with reverse assist
CUTTER DECK INFO.
Cutter Deck; Drive: 36” fabricated steel; belt driven
Cutting Height: 2" to 4" in 1/4” increments
No. of Blades 2 at 18” long
Spindle: aluminum housing with taper roller bearings, greasable
Pulleys: machined-cast iron for drive
PRODUCT SPECIFICATION
