-43-
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
1 603-0857 Idler Assembly 1
2 603-0203 Handle, Tension 2
3 703-0118 Idler Arm Assembly 1
4 918-3129B Spindle Assembly — Includes Ref.
Nos. 35, 36, 37 and 38
3
5 710-0923 Screw, Hex Cap, 5/8-18 x 3.0 1
6 710-1260A Screw, Hex Wash Ld, 5/16-18 x .75 12
7 710-1852 Bolt, Spindle, 3/4-16 x 5.37 3
8 710-3144 Screw, Hex Cap, 3/8-16 x 2.0 GR5 1
9 712-0239 Nut, Hex Lock, 1/2-20 1
10 712-0431 Nut, Flange Lock, 3/8-16 3
11 712-3019 Nut, Hex, 7/16-14, GR2 1
12 712-3078 Nut, Hex Flange, 3/4-16 3
13 716-3020 Snap Ring, Internal 2
14 732-0861 Spring, Ext, .162 Dia x 1.25 OD 1
15 732-3067 Torsion Spring, Idler, 1.10 ID x 1.3 1
16 736-0171 Washer, Lock, 7/16 1
17 736-0179 Washer, Flat, 1/2 x 1.25 x .10 1
18 736-0237 Washer, Flat, .65 x 1.25 x .075 2
19 737-3000 Fitting, Lube, 3/16 Drive 6
20 738-0143 Bolt, Shoulder, .498 Dia x .340 1
21 738-3172 Screw, Shldr, .68 x 2.11, 7/16-14 1
22 741-0338 Bearing, Flange, 3/4 ID x .52 LG 2
23 741-1122 Bearing, Ball 2
24 759-3939 Blade, Mower, 15.94 3
25 948-3020 Spacer, Blade 3
26 748-3065 Spacer, Deck Spindle 6
27 748-3100 Retainer, Spring 1
28 750-3119 Spacer, .406 ID x 1.00 OD x .38 1
29 750-3136 Spacer, .5 OD x .75 x 2.07 Lg 1
30 754-3039 V-Belt, 1/2 x 103.0 Lg 1
31 754-04041 V-Belt, B sect x 111.2 Lg 1
32 756-3005 Pulley, Flat w/Flanges 2
33 756-3089 Pulley, V-Type, 4.0 Dia 3
34 756-3115 Pulley, Double
Lube Fitting NOT included.
1
35 721-3018A Seal, Oil, 1.25 x 1.874 x .25 6
36 741-04089 Bearing, Cone 6
37 741-04091 Cup, Bearing 6
38 750-3190A Spacer, Bring, .780 x .963 x .777 3
39 750-3132 Spacer, .88 x .635 x 1.25 1
44" DECK DRIVE & SPINDLE ASSEMBLY
