Remove the clevis pins and hairpin clips from the e.
deck roller brackets on the left and right sides of the
f.
the slots on the rear of the deck until desired
position is reached, then reattach with the clevis
the left roller bracket and the right roller bracket are
set in the same position.
Refer to Leveling the Deck in the Maintenance section of this
manual for more detailed instructions regarding various deck
adjustments.
Adjusting the Seat
To adjust the position of the seat, pull up and hold the seat
desired position; then release the adjustment lever. Make sure
WARNING!
the seat is engaged in the seat-stop. Engage the
back on seat until it clicks into place.
Gas and Oil
The fuel tank is located under the fender and has a capacity
of three and-a-half gallons. Remove the fuel cap by turning it
old), unleaded gasoline. Fill the tank no higher than four inches
below the top of the filler neck to allow space for fuel expansion.
WARNING! Use extreme care when handling
gasoline. Gasoline is extremely flammable and the
vapors are explosive. Never fuel the machine
indoors or while the engine is hot or running.
Extinguish cigarettes, cigars, pipes and other
sources of ignition.
NOTE:
CAUTION: Always check the engine oil level before
so may result in serious damage to your engine.
Figure 3-5
11se c t i O n 2 — as s e M b l y & se t -up
