Cub Cadet i1046 Parts Manual

i1046 & i1050/Series i1000 SECTION HM12
13
Ref.
No.
Part No. Description
1 683-04256 Shield, Muffler
2 710-0227 Screw, Hex Wash Hd. Tapp, #8-18 x .5
3 710-0599 Screw, Hex Wash Hd. Tapp, 1/4-20 x .5
4 710-0642 Screw, Hex Wash Hd. Tapp, 1/4-20 x .75
5 710-0654A Screw, Hex Sems Tapp, 3/8-16 x 1.0
6 712-3005 Nut, Hex Flange Lock, 3/8-16 Gr5
7 725-0157 Tie, Cable
8 726-0154 Tie, Push Mount Cable
9 726-0205 Clamp, Hose
10 728-04000 Rivet, Pop, .188 x .3
11 736-0300 Washer, Flat, .406 x .875 x .059
12 751-0564B Deflector, Muffler
13 751-10006 Pipe, Exhaust RH
14 751-10007 Pipe Exhaust LH
15 751-10161 Muffler, Dual Inlet
16 751-10349 Hose, Fuel ; Low Permeation, 51 inches
17 751-10353 Deflector, Muffler
18 751-3140 Valve, Oil Drain
19 751-3141 Hose, Oil Drain Extension
20 751-3142 Cap, Drain Valve
21 783-04783 Shield, Heat
22 783-04870 Bracket, Muffler LH
23 783-04872 Bracket, Muffler RH
737-3030A Oil, 10W30 Engine
Engine Mounting & Connections

Cub Cadet i1046 Specifications

General

Engine Brand	Kohler
Engine Model	Courage
Cutting Width	46 inches
Transmission	Hydrostatic
Drive	Rear-wheel drive
Cutting Height	1.5 - 4 inches
Number of Blades	2
Blade Engagement	Electric PTO
Turning Radius	18 inches
Weight	580 lbs
Deck Material	Steel
Deck Type	Stamped
Engine Type	4-Cycle
Fuel Capacity	3.3 gallons
Warranty	3-year limited
