i1046 & i1050/Series i1000 SECTION HM12
15
Ref.
No.
Part No. Description
1 607-04342 Bracket, Steering Box Return
2 617-04036 Gear, Bevel LH
3 617-04037 Gear, Bevel RH
4 619-04153
737-0148
Housing, Steering Lower
Grease, Darina
5 619-04154 Housing, Steering Upper
6 647-04083 Arm, Hydro LH
7 647-04084 Arm, Hydro RH
8 647-04085 Cam, Hydro LH
9 647-04086 Cam, Hydro RH
10 703-2441 Arm, Neutral
11 710-0599 Screw, Hex Wash Hd. Tapp, 1/4-20 x .5
12 710-04040 Screw, Shoulder, .497 x .75 : 3/8-16
13 710-0778 Screw, Hex Wash Hd. Tapp, 1/4-20 x 1.5
14 710-0809 Screw, Hex Wash Hd. Tapp, 1/4-20 x 1.25
15 711-04587 Shaft, Steering
16 712-3005 Nut, Hex Flange Lock, 3/8-16 Gr5
17 716-0102 Ring, Snap, 1.0 Dia. Shaft
18 716-0111 Ring, External Retaining, .875 Shaft
19 716-0114 Ring, Retaining, .56 Dia. Shaft
20 716-0115 Ring, Retaining, .56 Dia. Shaft
21 716-04066 Ring, Retaining, .31125 Dia. Shaft
22 717-04318 Gear, Pinion, 7T
23 717-04319 Gear, Synchro Rack
24 717-04328 Gear, Steering, 17T
25 717-04330 Gear, Steering, 26T
26 718-04229 Tube, Coupler
27 718-04269 Cam, Hydro Steering
28 721-04186 O-Ring, .625 x .07
29 732-0306A Spring, Compression, .531 x 1.75
30 732-1162 Spring, Extension, .56 x 2.31 x .105
31 736-0369 Washer, Flat, .508 x 1.0 x .02
32 736-04237 Washer, Flat, .508 x 1.32 x .04
33 736-04257 Washer, Flat, 1.015 x 1.375 x .005
34 736-04258 Washer, Flat, 1.015 x 1.375 x .010
35 736-04259 Washer, Flat, 1.015 x 1.375 x .015
36 736-04260 Washer, Flat, 1.015 x 1.375 x .030
37 736-0864 Washer, Thrust, .375 x .812 x .06
39 741-04202 Bearing, Nylon Caster
40 741-04203 Bearing, Flange, .5 x .7
41 741-04204 Bearing, Sleeve, .437 x .3425
42 741-04206 Bearing, Sleeve, .623 x .5025 x .25
43 741-04231 Bearing, Sleeve, 1.2 x 1.0
44 741-04235 Bearing, Flange, .625 x .875
45 741-0747 Bearing, Ball, .5625 x 1.375 x .4375
Steering Gear Box
To Next Page
