Cub Cadet i1046

i1046 & i1050/Series i1000 SECTION HM12
25
Ref.
No.
Part No. Description
1 KH-32-028-01-S Dipstick Assembly (Incl. Ref.2)
2 KH-25-153-02-S O-Ring, Dipstick
3 KH-M-545013-S Screw, Flnge Thrd. Frmng M5 x .8 x 13
4 KH-12-123-04 Kit, Oil Fill Tube (Incl. Ref. 5,6)
5 KH-12-153-02-S O-ring, Upper Fill Tube
6 KH-12-153-01-S O-ring, Lower Fill Tube
7 KH-24-126-19 Bracket, Fill Tube
8 KH-24-032-01-S Seal, Oil
9 Crankcase - Use Short Block
10 KH-24-018-04 Retainer, Breather Reed
11 KH-12-402-02 Reed, Breather
12 KH-24-380-16-S Pin, Locating
13 KH-24-067-16-S Connecting Rod (Std.)
14 KH-32-874-06-S
KH-32-874-08-S
KH-32-874-09-S
Kit, Piston w/Ring Set (Std.)
Kit, Piston w/Ring Set (.25)
Kit, Piston w/Ring Set (.08)
15 KH-24-018-01-S Retainer, Piston Pin
16 KH-24-108-11-S
KH-24-108-06-S
Ring Set (Std. & .08)
Ring Set (.25)
17 KH-12-422-07-S
KH-12-422-08-S
KH-12-422-09-S
KH-12-422-10-S
KH-12-422-11-S
KH-12-422-12-S
KH-12-422-13-S
Shim, Camshaft (White .028)
Shim, Camshaft (Blue .03)
Shim, Camshaft (Red .032)
Shim, Camshaft (Yellow .034)
Shim, Camshaft (Green .036)
Shim, Camshaft (Gray .038)
Shim, Camshaft (Black .04)
18 KH-32-012-01-S Kit, Camshaft
19 KH-28-032-09-S Seal, Governor Cross Shaft
20 KH-24-018-09-S Retaining Ring
21 KH-M-931010-S Washer, Flat, 9mm
22 KH-24-468-15-S Washer, Flat, 11/32
23 KH-24-144-38-S Shaft, Governor Cross
24 KH-32-014-04-S Crankshaft (Incl. Ref. 25)
25 KH-52-139-09-S Plug, Cup
i1046 & i1050 Crankcase; Crankshaft; and Dipstick
