Cub Cadet i1046 Parts Manual

i1046 & i1050/Series i1000 SECTION HM12
29
Ref.
No.
Part No. Description
1 KH-32-027-03-S Kit, Blower Hsng (Incl. Ref.2 &
KH-41-037-10-S)
2 KH-32-096-08-S Cover, Air Cleaner
3 KH-M-545016-S Screw, Flnge Thrd. Frmng M5 x 0.8x 16
4 KH-M-645016-S Screw, Flnge Thrd. Frmng M6 x 1.0 x 16
5 KH-32-146-05-S Plate, Backing
6 KH-32-063-05-S Baffle, Cyl. Barrel - #2 Side
7 KH-M-545010-S Screw, Flnge Thrd. Frmng M5 x 0.8x 10
8 KH-32-063-02-S Baffle, Valley #2 Side
9 KH-32-063-03-S Baffle, Valley #1 Side
10 KH-32-063-06-S Baffle, Cylinder Barrel - #1 Side
11 KH-24-086-12-S Screw, Tap, M6 x 1.7 x 18
Not Illustrated
KH-41-037-10-S Nameplate, Service
KH-32-113-20-S Decal, Cub
i1046 & i1050 Blower Housing/Baffles

Cub Cadet i1046 Specifications

General

Engine Brand	Kohler
Engine Model	Courage
Cutting Width	46 inches
Transmission	Hydrostatic
Drive	Rear-wheel drive
Cutting Height	1.5 - 4 inches
Number of Blades	2
Blade Engagement	Electric PTO
Turning Radius	18 inches
Weight	580 lbs
Deck Material	Steel
Deck Type	Stamped
Engine Type	4-Cycle
Fuel Capacity	3.3 gallons
Warranty	3-year limited
