Cub Cadet i1046 Parts Manual

i1046 & i1050/Series i1000 SECTION HM12
33
Ref.
No.
Part No. Description
1 KH-32-162-03-S Screen, Grass
2 KH-12-086-14 Screw, Flange, M10 x 1.5 x 45
3 KH-12-468-03 Washer, Flat 13/32
4 KH-20-146-02-S Plate, Fan Mounting
5 KH-32-157-01-S Fan
6 KH-32-025-08-S Flywheel
7 KH-X-42-15 Key, 3/16 x 5/8
8 KH-236602-S Connector (3 Contact)
9 KH-M-551016-S Screw, Flange, M5 x 0.8 x 16
10 KH-41-403-09 Rectifier-Regulator
11 KH-237878 Kit, 15 Amp Stator
12 KH-235173 Clip, Cable
13 KH-M-548025-S Screw, Thrd. Frmng M5 x 0.8x 25
14 759-3336 Plug, Spark
15 KH-24-584-45-S Module, Ignition
16 KH-M-545020-S Screw, Flnge Thrd. Frmng M5 x 0.8x 20
Not Illustrated
KH-25-454-03-S Tie, Wire
KH-32-176-02-S Harness, Wiring
i1046 & i1050 Flywheel/Electrical

Cub Cadet i1046 Specifications

General

Engine Brand	Kohler
Engine Model	Courage
Cutting Width	46 inches
Transmission	Hydrostatic
Drive	Rear-wheel drive
Cutting Height	1.5 - 4 inches
Number of Blades	2
Blade Engagement	Electric PTO
Turning Radius	18 inches
Weight	580 lbs
Deck Material	Steel
Deck Type	Stamped
Engine Type	4-Cycle
Fuel Capacity	3.3 gallons
Warranty	3-year limited
