Cub Cadet i1046 Parts Manual

i1046 & i1050/Series i1000 SECTION HM12
37
Ref.
No.
Part No. Description
1 KH-24-211-03-S Bolt, Carriage, M6 X 1.0 X 25
2 KH-24-090-33-S Lever, Governor
3 KH-M-641060-S Nut, Flange, M6 x 1.0
4 KH-24-089-01 Spring, Linkage
5 KH-25-158-08 Bushing, Linkage Retainer
6 KH-24-079-04 Linkage, Throttle
7 KH-25-158-11 Bushing, Throttle Linkage
8 KH-M-545016-S Screw, Flng. Thrd. Frmng, M5 x 0.8 x 16
9 KH-M-547050-S Nut, Lock, M5 x 0.8
10 KH-24-083-03 Spring, Choke Return
11 KH24-126-161-S Bracket, Control
12 KH-M-645016-S Screw, Flnge Thrd. Frmng M6 x 1.0 x 16
13 KH-47-237-02 Clamp, Dual Conduit
14 KH-24-086-43-S Screw, Torx Hd. Ctsk, M5 x 0.8 x 16
15 KH-24-079-22-S Linkage, Choke
16 KH-24-112-27-S Spacer, Control Assembly
17 KH-24-090-47-S Lever, Throttle Actuator
18 KH-24-090-13 Lever, Throttle Control
19 KH-24-468-01 Washer, Flat, 5.5mm
20 KH-M-545020-S Screw, Flng. Thrd. Frmng, M5 x 0.8 x 20
21 KH-41-468-03 Washer, Spring, 1/4
22 KH-24-090-05 Lever, Choke
23 KH-M-403025 Screw, Hex Cap, M4 x 0.7 x 25
24 KH-M-446030-S Nut, M4 x 0.7
25 KH-24-468-20-S Washer, Flat, 5mm
26 KH-24-089-55-S Spring, Governor
27 KH-24-089-18
KH-24-089-25-S
Spring, Governor, Model i1046 ONLY
Spring, Governor, Model i1050 ONLY
i1046 & i1050 Engine Controls
