Lock
Jet Sweep Blower controls and features are illustrated in Fig 4-1 and described below.
Read and follow all safety rules and instructions in this manual, including the entire Operation section,
before attempting to operate this machine. Failure to comply with all safety rules and instructions may result in personal
injury.
Blower Direction Lever
The air flow can be directed to one
of three directions using the blower
direction lever to reposition the louvers.
Do not stand
in front of discharge area.
BLOWER DIRECTION LEVER
UP
AIR FLOW
DOWN
Engine
Refer to the Honda Owner’s Manual for details regarding all
engine-related controls and features.
Caster Wheel Lock
The front caster wheel can be locked in position for straight
ahead travel or allowed to swivel freely.
Controls and Features
4
